The SA-3 Fast Wall (sealed air) work tent is a rapidly deployed air building suitable for a wide range of construction & maintenance applications in tough operational environments.
Supplied as a 3 m (9’10″) long module. The Fast Wall can be used as a ‘standalone’ building or multiple modules can be joined together (end walls are removable).
The 3 m (9’10”) wide Fast Module can also be joined along the centre line, to create a 6 m (20’) wide work tent.
Buy from stock in our signature orange & grey colour scheme or we can build to order in a choice of 12 colours, customised with your company logo.
Need something larger? We have work tents up to 12 m (39″4’) wide in our SA Range.
Specifications
Dimensions
- Width, outside 3 m (9'2")
- Width, inside 2.4 m (7'10")
- Length 3 (9'2")
- Height, outside 3 m (9’10”)
- Height, inside 2.7 m (8’10″)
- Packed Size 1 x 0.9 x 0.9 m (3′ x 3′ x 3′)
- Weight 72 kg (159 lbs)
Construction
- Frame Plato 1140 gsm PVC (FR) 30 cm (12") diameter
- Side Walls 630 gsm PVC (flame retardant)
- End Walls 2 x removable – 630gsm PVC (flame retardant)
- Roof 620 gsm PVC (flame retardant) with clear PVC panels
- Module Connection 7 x dutch lacing sections + rain cover
Standard Features
- Windows 4 x clear PVC windows – 60 cm x 90 cm (23″ x 35″)
- Access 1 x personnel door (each end wall)
- Fans Sealed air fan with automatic pressure control
- Fill Points 2 x fill points with pressure release
- Deflation Zips n/a
- Internal Ties 30 x webbing loops
- Document Pouch 1 x A4 clear external pouch (each end wall)
- Duct Holes 2 x 300mm (12″) ducting holes with velcro flap
Anchors (Each side)
- High Level n/a
- Mid Level 3 x heavy duty, multi directional webbing – 150 kg (330 lbs) capacity (each side)
- Ground Level 5 x heavy duty metal ring – 150 kg (330 lbs) capacity (each side)
Anchors (Each end)
- High Level n/a
- Ground Level 4 x heavy duty, multi directional webbing – 150 kg (330lbs) capacity (each end)
Standard Accessories
- Transport Bag 1 x PVC transport bag
- Repair Kit Included
- Stakes Reinforced steel, 18 mm (11/16”) diameter
- Ties 10 mm (3/8″) polypropylene rope
- Colours (Build to order) 12
Branding / Logos
- Side Walls 1 x removable digitally printed PVC banner – 141 cm L x 129 cm H (4′ 7″ x 4′ 2″) (each side)
- End Walls n/a
- Note Specification and dimensions may be subject to change without notice
What's Included With Your
Sealed Air Fast Tent
A Sealed Air Tent is supplied as a 'turnkey' solution with everything you need to get going.
1m pegs
Anchoring Ropes
Fan(s)
Operational Manual
Repair Kit
Standard pegs
Transport & storage bag
Webbing ropesInflatable Work
Tent Installation
& Set Up
With no loose parts or components, Njordair inflatable buildings are simple and easy to use. Our on site set up & product familiarization service for new customers
provides total peace of mind. We’ve got your back.
Fast Tent Purchase Options
Standard design & orange / grey colour
scheme with Njordair branding.
Typical lead time 7 days.
Custom design, colour or branding.
Typical lead time 8-12 weeks.
Related Products
Meters
Feet
-
SA-2 Inflatable Work Tent
-
Width, outside2 m (6’6″)
-
Width, inside1.5 m (4′11")
-
Length5 m (16′5")
-
Height, outside2.25 m (7’5″)
-
Height, inside2 m (6″6′)
-
-
SA-3 Inflatable Work Tent
-
Width, outside3 m (9'2")
-
Width, inside2.4 m (7'10")
-
Length3 (9'2")
-
Height, outside3 m (9’10”)
-
Height, inside2.7 m (8’10″)
-
-
SA-4 Inflatable Work Tent
-
Width, outside4 m (13′1")
-
Width, inside3.3 m (10′10")
-
Length5 m (16′5")
-
Height, outside3.15 m (10′4″)
-
Height, inside2.8 m (9'2"))
-
-
SA-6 Inflatable Work Tent
-
Width, outside6 m (19′8")
-
Width, inside5.4 m (17′9")
-
Length5m (16′)
-
Height, outside3.45 m (10’4”)
-
Height, inside2.85m (9'4")
-
-
SA-8 Inflatable Work Tent
-
Width, outside8 m (26′3")
-
Width, inside7 m (23′)
-
Length5 m (16′5")
-
Height, outside4.5 m (14’9”)
-
Height, inside4 m (13″1′)
-
-
SA-10 Inflatable Work Tent
-
Width, outside10 m (32′10")
-
Width, inside8.8 m (28′11")
-
Length5 m (16′5")
-
Height, outside5.5 m (18')
-
Height, inside4.9 m (16'1")
-
-
SA-12 Inflatable Work Tent
-
Width, outside12 m (39′4")
-
Width, inside10.4 m (34′1")
-
Length5 m (16′5")
-
Height, outside6.5 m (21’4”)
-
Height, inside5.9 m (8'6")
-
